380V/400A, DC Inverter, IGBT Module TIG Machine Welding
Tool/Equipment Welder with MMA Function
IGBT Module TIG Welding Machine Main features:
1. The digitization control circuit, full functions and regulate
easily.
2. DC pulse argon arc welding, DC argon arc welding, DC ARC welding
three functions.
3. Mainly use for the welding of stainless steel, mild steel,
high-strength steel, copper and the other alloys materials.
4. Applicate extensively with aerospace, locomotive, ship, press
container, petrochemical, motorbike, bicycle, hydropower, steel
wood furniture fields and so on.
5. Digitization inverter technology, greatly improve the whole
machine's performance and reliability.
6. Welding control exact, high arcing success rate.
TIG Welding Machine Technical Parameter:
Type | TIG400MIJ |
control mode | IGBT inverter |
Rated input voltage | AC380V |
Rated input capacity(KVA) | 18.4 |
Cable cross-sectional area | mains input(mm2) | 6 |
power output(mm2) | 50 |
ground wire(mm2) | 4 |
Duty cycle(%) | 60 |
Rated output no-load voltage(V) | 72 |
Output current adjustment range(A) | 5-400 |
Starting current adjustment range(A) | 10-160 |
Pulse frequency(HZ) | 0.2-50 |
Arc ignition mode | High frequency arc striking |
Enclosure rating | IP21S |
Insulation rating | F |
Cooling method | Air |
Power factor | 0.93 |
Dimensions(mm) | 560*290*530 |
Host weight(KG) | 25 |
Introduction to the principle of electric welding machine:
The electric welding machine, which uses inductance to make contact
and the object to be touched to complete the welding function, is
actually an extremely high power transformer, which can complete
the conversion of electric energy to thermal energy in an instant,
with the advantages of simple operation, convenient carrying, fast
speed and strong performance, it has been widely used, whether in
actual use or in the school laboratory.
FAQ:
Q: Are you a factory or trading company?
A: We are trading company with our own factory with more than 10
assembly product line and strict QC system and equipment, so we can
meet both your quantity and quality demands.
Q: Can I get some samples?
A: Yes,we are glad to offer you samples.After price and order
confirmed, the samples fee will be regressed.
MOQ:Generally if you choose the different products,our minimum
order qty.also will be different.
Payment: Acturally, payment would be preferred: Normally we choose
in T/T, usually is 30% deposit and pay the balance before
shipment.L/C, Western Union is fine.
Q: When can I get the products?
A: You products will be arrived your the nearest domestic port
after order confirmed, it's about 30 days.
