High Quality Inverter Welding Machine MIG630 3 phase 380V
IGBT inverter Features:
1 IGBT inverter with MIG,MMA,and gasless FCAW functions
2 Adopt inverter technology, stable welding.
3 New arc control technology, arc choose is easy and efficient.
4 Wide welding current range, good performance under high-speed
welding.
5 Multiple protection functions: output short-circuit protection,
overheat protection, inverter overcurrent or overvoltage
protection.
6 Digital panel,current/voltage preview function,wide range match in
current and voltage
Technical parameters
Type | MIG630 |
Control mode | IGBT inverter |
Rated input voltage | AC380V |
Input power frequency(HZ) | 50/60 |
Rated input current(A) | 82 |
Rated input capacity(KVA) | 54 |
Cable cross-sectional area | Main input(MM2) | 10 |
Power output(MM2) | 70 |
Ground(MM2) | 4 |
Rated output voltage(V) | 44 |
Duty cycle(%) | 60 |
Rated output no-load voltage(V) | 75 |
Current adjustment range(A) | 80-630 |
Voltage adjustment range(V) | 17-44 |
Power factor | 0.93 |
Enclosure rating | IP21S |
Insulation rating | F |
Cooling method | Air |
Weldable sheet thickness(MM) | 2.5-40 |
Adapt welding wire diameter(solid core)(MM) | 1.2/1.4/1.6 |
Adapt welding wire diameter(drug core)(MM) | 1.2/1.4/1.6 |
Dimensions(MM) | 620*310*650 |
Host weight(KG) | 40 |
Our factory
Our Services
1. Your inquiry related to our product & price will be replied
within 24 hours
2. Well-trained & experienced staff are to answer all your
inquiries in English
3. Working time: 8:00am ~17:30pm, Monday to Saturday. (UTC+8)
4. Customized solution & perfect after-sale service
5. For large order, engineer can be sent to your country for
on-site mainternace
instructions.
6. Our advantage: (1)Competitive price (2). Good quality (3).
Timely delivery (4) New model launch yearly(5) Own manufacturing (6) Own quality control.
FAQ
Q:What makes you different from other welding machines companies?
A:We work in the hardware capital of China and we know most of the
welding machines factories working methods, culture, business
style, key persons and other relevant details. We look beyond a
welding machines business which is just product based. We strongly
believe that having a good positive working culture and put
together a skilled and motivated team can reflect on our welding
products and the service provided to our customers.
Q:Can you make your welding machines under my brand?
A:Yes, we can welding machines under your logo and it has the
Minimum Order Quantity .
Q:I have not heard of General Welder company before, are you a new
company?
A:General Welder company was established since 2012 by a team of
members with welding machines exceptional knowledge and with over
10 years of experience in the welding machines Industry
